ZU045MZ3 RBC

Brand - RBC
Item Number - ZU045MZ3*RBC
Category - SIMPLEX™ Series Thin Section Ball Bearings

Principal Dimensions & Load Ratings (Imperial) :
Bore Diameter (B) - 4.5 inch
Outside Diameter (D) - 5.25 inch
Width (W) - 0.5 inch
Recess Diameter (Gi) - 4.655 inch
Groove Diameter (Mo) - 5.05 inch
Ball Diameter - 0.125 inch
Ball Quantity - 60 pcs
Approximate Weight - 0.61 lbs
Radial Static Load - 995 lbf
Radial Dynamic Load - 660 lbf
Thrust Static Load - 2990 lbf
Thrust Dynamic Load - 1915 lbf
Moment Static Load - 5070 lbf-in
Moment Dynamic Load - 1840 lbf-in

Principal Dimensions & Load Ratings (Metric) :
Bore Diameter (B) - 114.3 mm
Outside Diameter (D) - 133.35 mm
Width (W) - 12.7 mm
Recess Diameter (Gi) - 118.24 mm
Groove Diameter (Mo) - 128.27 mm
Approximate Weight - 0.277 kg
Radial Static Load - 4430 N
Radial Dynamic Load - 2940 N
Thrust Static Load - 13300 N
Thrust Dynamic Load - 8520 N
Moment Static Load - 570 Nm
Moment Dynamic Load - 210 Nm

Description of Suffixes and Prefixes :
U - Extra Extended Width
M - Double Angular Ball Contact
3 - ABEC 3F

Other salient point to be noted :
* Radial load rating is two times the value per row ideally if both rows share load equally.
