Description
Brand - INA
Item Number - ZKLFA1263-2Z INA
Category - Angular Contact Ball Bearing Double Row
Also known as - 1307100000
Inner (d) MM - 12
Outer (D) MM - 42
Width (B) MM - 25
Inner (d) Inch - 0.4724
Outer (D) Inch - 1.6535
Width (B) Inch - 0.9843
Weight (kg) - 0.3
Bore - C - Cylindrical Bore
Seal - ZZ/2Z - Steel Seal on Two Sides
Cage Type - S - Steel or Standard Cage
External Modification - No External Modification
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Lubrication - Standard Lubrication
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring - Split innerring
** Images are for representation purposes only
