Description
Brand - FAG
Item Number - Z-580510.ZL FAG
Category - Four Row Cylindrical Roller Bearings with Cage
Weight (Kg) - 100
Inner Diameter (d) mm - 220
Outer Diameter (D) mm - 340
Inner Width (B) mm - 320
Width, Outer Ring (C) mm - 290
Raceway Diameter Inner Ring (F) mm - 250
Minimum Chamfer Dimension (r) mm - 3
Minimum Chamfer Dimension (r1) mm - 2
Basic Dynamic Load Rating (Cr) kN - 3550
Basic Static Load Rating (C0r) kN - 5850
Fatigue Limit Load (Cur) kN - 640
