Description
Brand - FAG
Item Number - Z-568450.ZL FAG
Category - Four Row Cylindrical Roller Bearings with Cage
Weight (Kg) - 220
Inner Diameter (d) mm - 350
Outer Diameter (D) mm - 520
Inner Width (B) mm - 300
Raceway Diameter Inner Ring (F) mm - 401
Minimum Chamfer Dimension (r) mm - 5
Minimum Chamfer Dimension (r1) mm - 5
Basic Dynamic Load Rating (Cr) kN - 5100
Basic Static Load Rating (C0r) kN - 8800
Fatigue Limit Load (Cur) kN - 830
