Description
Brand - FAG
Item Number - Z-567725.01.ZL FAG
Category - Four Row Cylindrical Roller Bearings with Cage
Weight (Kg) - 513
Inner Diameter (d) mm - 510
Outer Diameter (D) mm - 680
Inner Width (B) mm - 500
Raceway Diameter Inner Ring (F) mm - 560
Minimum Chamfer Dimension (r) mm - 7.5
Minimum Chamfer Dimension (r1) mm - 3
Basic Dynamic Load Rating (Cr) kN - 10400
Basic Static Load Rating (C0r) kN - 25500
Fatigue Limit Load (Cur) kN - 2300
