Description
Brand - FAG
Item Number - Z-560507.ZL FAG
Category - Four Row Cylindrical Roller Bearings with Cage
Weight (Kg) - 815
Inner Diameter (d) mm - 536.176
Outer Diameter (D) mm - 762.03
Inner Width (B) mm - 559
Raceway Diameter Inner Ring (F) mm - 598
Minimum Chamfer Dimension (r) mm - 5
Minimum Chamfer Dimension (r1) mm - 2
Basic Dynamic Load Rating (Cr) kN - 14600
Basic Static Load Rating (C0r) kN - 31500
Fatigue Limit Load (Cur) kN - 2750
