Z-549875.ZL FAG


Country Of Origin: Imported
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - FAG
Item Number - Z-549875.ZL FAG
Category - Cylindrical Roller Bearings with Cage Double Row
Weight (Kg) - 452
Inner Diameter (d) mm - 550
Outer Diameter (D) mm - 800
Inner Width (B) mm - 260
Minimum Chamfer Dimension (r) mm - 6
Raceway Diameter Inner Ring (F) mm - 612
Shoulder Diameter Outer Ring (D1) mm - 721
Diameter Lubrication Hole (ds) mm - 12.5
Width of Lubricating Groove (ns) mm - 23.5
Maximum Fillet Radius of Shaft (ra) mm - 5
Basic Dynamic Load Rating (Cr) kN - 6100
Basic Static Load Rating (C0r) kN - 14600
Fatigue Limit Load (Cur) kN - 1220
Limiting Speed (nG) rpm - 800
