Z-549822 INA


Country Of Origin: EU
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - INA
Item Number - Z-549822 INA
Category - Crossed Cylindrical Roller (Adjustable Preload)
Inner Diameter (d) mm - 3500
Outer Diameter (D) mm - 3920
Width (B) mm - 140
Weight (m) kg - 2286
Minimum Chamfer Dimension (r min) mm - 6
Minimum Mounting Dimension (D1) mm - 3685
Maximum Mounting Dimension (D2) mm - 3777
Maximum Mounting Dimension (ra) mm - 5
Basic Dynamic Load Rating (C) kN - 4250
Basic Static Load Rating (C0) kN - 38000
Limiting Speed for Grease Lubrication (nG grease) 1/min - 20
Limiting Speed for Oil Lubrication (nG oil) 1/min - 43
Grease Quantity for Initial Greasing (kg) - 18

** Images are for representation purposes only
