Description
Brand - FAG
Item Number - Z-532381.ZL-N12BA FAG
Category - Four Row Cylindrical Roller Bearings with Cage
Weight (Kg) - 122
Inner Diameter (d) mm - 350
Outer Diameter (D) mm - 500
Inner Width (B) mm - 380
Raceway Diameter Inner Ring (F) mm - 389
Minimum Chamfer Dimension (r) mm - 5
Minimum Chamfer Dimension (r1) mm - 5
Basic Dynamic Load Rating (Cr) kN - 4200
Basic Static Load Rating (C0r) kN - 11200
Fatigue Limit Load (Cur) kN - 940
