Description
Brand - FAG
Item Number - Z-529031.01.ZL FAG
Category - Split Cylindrical Roller Bearings
Weight (Kg) - 470
Inner Diameter (d) mm - 799.8
Outer Diameter (D) mm - 1080
Inner Width (B) mm - 210
Width, Outer Ring (C) mm - 128
Minimum Chamfer Dimension (r) mm - 9.5
Minimum Chamfer Dimension (r1) mm - 9.5
Basic Dynamic Load Rating (Cr) kN - 4050
Basic Static Load Rating (C0r) kN - 9000
Fatigue Limit Load (Cur) kN - 600
