Description
Brand - FAG
Item Number - Z-524544.01.ZL FAG
Category - Four Row Cylindrical Roller Bearings with Cage
Weight (Kg) - 849
Inner Diameter (d) mm - 536.176
Outer Diameter (D) mm - 762.03
Inner Width (B) mm - 559
Raceway Diameter Inner Ring (F) mm - 598
Minimum Chamfer Dimension (r1) mm - 3
Basic Dynamic Load Rating (Cr) kN - 13400
Basic Static Load Rating (C0r) kN - 30000
Fatigue Limit Load (Cur) kN - 2650
