Description
Brand - FAG
Item Number - Z-518214.ZL FAG
Category - Four Row Cylindrical Roller Bearings with Cage
Weight (Kg) - 134
Inner Diameter (d) mm - 260
Outer Diameter (D) mm - 400
Inner Width (B) mm - 290
Raceway Diameter Inner Ring (F) mm - 296
Minimum Chamfer Dimension (r) mm - 4
Minimum Chamfer Dimension (r1) mm - 4
Basic Dynamic Load Rating (Cr) kN - 4000
Basic Static Load Rating (C0r) kN - 6800
Fatigue Limit Load (Cur) kN - 710
