Description
Brand - FAG
Item Number - Z-517680.01.ZL FAG
Category - Four Row Cylindrical Roller Bearings with Cage
Weight (Kg) - 1820
Inner Diameter (d) mm - 710
Outer Diameter (D) mm - 1000
Inner Width (B) mm - 715
Raceway Diameter Inner Ring (F) mm - 787.5
Minimum Chamfer Dimension (r1) mm - 4
Basic Dynamic Load Rating (Cr) kN - 23200
Basic Static Load Rating (C0r) kN - 53000
Fatigue Limit Load (Cur) kN - 4250
