Description
Brand - FAG
Item Number - Z-513729.01.ZL FAG
Category - Four Row Cylindrical Roller Bearings with Cage
Weight (Kg) - 101
Inner Diameter (d) mm - 280
Outer Diameter (D) mm - 390
Inner Width (B) mm - 275
Raceway Diameter Inner Ring (F) mm - 312
Minimum Chamfer Dimension (r) mm - 2.1
Minimum Chamfer Dimension (r1) mm - 2.1
Basic Dynamic Load Rating (Cr) kN - 3150
Basic Static Load Rating (C0r) kN - 6400
Fatigue Limit Load (Cur) kN - 670
