Description
Brand - FAG
Item Number - Z-510036.TR4 FAG
Category - Four-Row Tapered Roller Bearing
Weight (Kg) - 1000
Inner Diameter (d) mm - 420
Outer Diameter (D) mm - 760
Outer Width (T) mm - 500
Inner Width (B) mm - 500
Basic Dynanic Load Rating (Cr) kN - 12300
Basic Static Load Rating (C0r) kN - 20200
Dynamic Axial Load Factor (Y1) - 1.95
Dynamic Axial Load Factor (Y2) - 2.9
Static Axial Load Factor (Y0) - 1.9
Fatigue Limit Load (Cur) kN - 1700
