Description
Brand - FAG
Item Number - Z-507747.TR4 FAG
Category - Four-Row Tapered Roller Bearing
Weight (Kg) - 104
Inner Diameter (d) mm - 215.9
Outer Diameter (D) mm - 355.6
Outer Width (T) mm - 254
Inner Width (B) mm - 254
Basic Dynanic Load Rating (Cr) kN - 3050
Basic Static Load Rating (C0r) kN - 5400
Dynamic Axial Load Factor (Y1) - 1.96
Dynamic Axial Load Factor (Y2) - 2.91
Static Axial Load Factor (Y0) - 1.91
Fatigue Limit Load (Cur) kN - 580
