Description
Brand - FAG
Item Number - WS22217-E1-XL-K-2RSR FAG
Category - Sealed Spherical Roller Bearing
Weight (m) kg - 3
Inner Diameter (d) mm - 85
Outer Diameter (D) mm - 150
Width (B) mm - 44
Minimum Chamfer Dimension (r) mm - 2
Outer Ring Bore Diameter (D1) mm - 137.1
Inner Ring Raceway Diameter (d2) mm - 96.5
Lubrication Hole Diameter (ds) mm - 3.2
Lubrication Groove Width (ns) mm - 6.5
Minimum Abutment Diameter of Shaft Shoulder (da) mm - 96
Maximum Housing Connection Diameter (Da) mm - 139
Maximum Undercut Radius (ra) mm - 2
Basic dynamic Radial Load Rating (Cr) N - 305000
Basic Static Radial Load Rating (C0r) N - 325000
Calculation Factor (e) - 0.22
Calculation Factor (Y1) - 3.04
Calculation Factor (Y2) - 4.53
Calculation Factor (Y0) - 2.97
Radial Fatigue Load Limit (Cur) N - 39000
Limiting Speed (nG) 1/min - 1420
Adapter Sleeve - H2217-T-WS
Withdrawal Sleeve - AH2217-WS
Suffixes:
E1 - Without Central Rib on Inner Ring
XL - X-Life
K - Tapered Bore (Taper 1:12)
2RSR - Steel-Reinforced Lip Seal on Both Sides Made From Nitrile Rubber (NBR), Grease Filling Level 25% to 40%, Filled with High-Pressure Grease
