WS22216-E1-XL-K-2RSR FAG


Country Of Origin: Imported
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - FAG
Item Number - WS22216-E1-XL-K-2RSR FAG
Category - Sealed Spherical Roller Bearing
Weight (m) kg - 2.3
Inner Diameter (d) mm - 80
Outer Diameter (D) mm - 140
Width (B) mm - 40
Minimum Chamfer Dimension (r) mm - 2
Outer Ring Bore Diameter (D1) mm - 128.6
Inner Ring Raceway Diameter (d2) mm - 91.3
Lubrication Hole Diameter (ds) mm - 3.2
Lubrication Groove Width (ns) mm - 6.5
Minimum Abutment Diameter of Shaft Shoulder (da) mm - 91
Maximum Housing Connection Diameter (Da) mm - 129
Maximum Undercut Radius (ra) mm - 2
Basic dynamic Radial Load Rating (Cr) N - 250000
Basic Static Radial Load Rating (C0r) N - 270000
Calculation Factor (e) - 0.22
Calculation Factor (Y1) - 3.14
Calculation Factor (Y2) - 4.67
Calculation Factor (Y0) - 3.07
Radial Fatigue Load Limit (Cur) N - 34500
Limiting Speed (nG) 1/min - 1540
Adapter Sleeve - H2216-T-WS
Withdrawal Sleeve - AH2216-WS

Suffixes:
E1 - Without Central Rib on Inner Ring
XL - X-Life
K - Tapered Bore (Taper 1:12)
2RSR - Steel-Reinforced Lip Seal on Both Sides Made From Nitrile Rubber (NBR), Grease Filling Level 25% to 40%, Filled with High-Pressure Grease

** Images are for representation purposes only
