WD460 WD

Brand - WD
Item Number - WD460 WD
Category - Eccentric Adjustable Combined Roller Bearing

Principal Dimensions & Load Ratings (Metric):
Bore Diameter - 55 mm
Dimension (T) - 69 mm
Outside Diameter - 107.7 mm
Dimension (H) - 54 to 56 mm
Dimension (h) - 40 to 42 mm
Overall Bearing Width - 31 mm
Dimension (A) - 4 to 6 mm
Dimension (S) - 30 mm
Dimension (r) - 4 mm
Optional Outer Diameter - 111.8 mm
Reference Code in Germany - 4.46
Reference Code in Italy (A) - 4.046
Basic Load Rating (C) - 81 kN
Basic Load Rating (Co) - 95 kN
Dynamic Basic Load Rating (Ca) - 25 kN
Static Basic Load Rating (Coa) - 27 kN

♦ ♦ Images are for representation purposes only
