WD454 WD

Brand - WD
Item Number - WD454 WD
Category - Eccentric Adjustable Combined Roller Bearing

Principal Dimensions & Load Ratings (Metric):
Bore Diameter - 30 mm
Dimension (T) - 42 mm
Outside Diameter - 62.5 mm
Dimension (H) - 37.5 to 39 mm
Dimension (h) - 30.5 to 32 mm
Overall Bearing Width - 20 mm
Dimension (A) - 4 to 5.5 mm
Dimension (S) - 20 mm
Dimension (r) - 3 mm
Optional Outer Diameter - 62 mm, 64.8 mm
Reference Code in Germany - 4.454
Reference Code in Italy (A) - 4.0454
Basic Load Rating (C) - 31 kN
Basic Load Rating (Co) - 35.5 kN
Dynamic Basic Load Rating (Ca) - 11 kN
Static Basic Load Rating (Coa) - 11 kN
