WD0784-107.7 WD

Brand - WD
Item Number - WD0784-107.7 WD
Category - Adjustable Combined Roller Bearing with Shims

Principal Dimensions & Load Ratings (Metric):
Bore Diameter - 60 mm
Dimension (T) - 71 mm
Outside Diameter - 107.7 mm
Dimension (H) - 69 mm
Dimension (h) - 55 mm
Overall Bearing Width - 31 mm
Dimension (A) - 8.5 mm
Dimension (S) - 33 mm
Dimension (r) - 5 mm
Optional Outer Diameter - 111.8 mm
Reference Code in Germany - 4.0784
Basic Load Rating (C) - 81 kN
Basic Load Rating (Co) - 95 kN
Dynamic Basic Load Rating (Ca) - 31 kN
Static Basic Load Rating (Coa) - 36 kN

♦ ♦ Images are for representation purposes only
