WD073-70.1 WD

Brand - WD
Item Number - WD073-70.1 WD
Category - Adjustable Combined Roller Bearing with Shims

Principal Dimensions & Load Ratings (Metric):
Bore Diameter - 35 mm
Dimension (T) - 48 mm
Outside Diameter - 70.1 mm
Dimension (H) - 48 mm
Dimension (h) - 40 mm
Overall Bearing Width - 23 mm
Dimension (A) - 6 mm
Dimension (S) - 16 mm
Dimension (r) - 4.5 mm
Optional Outer Diameter - 70.7 mm, 73.8 mm
Reference Code in Germany - 4.073
Reference Code in Italy - MR.147
Basic Load Rating (C) - 45.5 kN
Basic Load Rating (Co) - 51 kN
Dynamic Basic Load Rating (Ca) - 8 kN
Static Basic Load Rating (Coa) - 8 kN
