WD056/77.7-ZRS WD

Brand - WD
Item Number - WD056/77.7-ZRS WD
Category - Standard Combined Roller Bearing

Principal Dimensions & Load Ratings (Metric):
Bore Diameter - 40 mm
Outside Diameter - 77.7 mm
Dimension (C) - 23 mm
Dimension (H)   - 48 mm
Dimension (H1) - 36.5 mm
Dimension (H2) - 11.5 mm
Outside Diameter - 61 mm
Dimension (C1) - 26 mm
Dimension (d1) - 53 mm
Dimension (S) - 3 mm
Angle - 20 º
Dimension (r) - 4.5 mm
Dimension (R) - 700 mm
Dimension (R1) - 700 mm
Dimension (V) - M6X1
Optional Outer Diameter - 78.1 mm, 81.8 mm
Basic Load Rating (C) - 48 kN
Basic Load Rating (Co) - 56.8 kN
Dynamic Basic Load Rating (Ca) - 18 kN
Static Basic Load Rating (Coa) - 18 kN
Reference Code in Germany - 4.056
Reference Code in Italy (A) - 4.0056-77.7
Reference Code in Italy (B) - MR.003
