Description
Brand - IKO
Item Number - TAF 243220/SG IKO
Also Known As - TAF243220/SG
Category - C-Lube Machined Type Needle Roller Bearing without Inner Ring
Shaft Diameter (mm) - 24
Boundary Dimension (Fw) mm - 24
Outer Diameter (D) mm - 32
Boundary Dimension (C) mm - 20
Minimum Standard Mounting Dimension (rs) mm - 0.3
Maximum Standard Mounting Dimension (Da) mm - 30
Basic Dynamic Load Rating (C) N - 19400
Basic Static Load Rating (C0) N - 30500
Weight (kg) - 0.042
** Images are for representation purposes only
