T4 FR 22 150 NADELLA

Brand - NADELLA
Item Number - T4 FR 22 150 NADELLA
Category - Carriages with Anodised Aluminium Body with Four Guide Rollers

Principal Dimensions & Load Ratings (Metric):
Dimension (L) - 150 mm
Dimension (B) - 90 mm
Dimension (Ix) - 119 mm
Dimension (Iy) - 58.7 mm
Dimension (H) - 42.4 mm
Dimension (H1) - 28.4 mm
Dimension (H2) - 19 mm
Dimension (G) - M6
Dimension (b) - 15 mm
Weight - 0.9 kg
Suggested Combinations - FWS 22

♦ ♦ Images are for representation purposes only
