Description
Brand - KAYDON
Item Number - T01-00625NAA KAYDON
Also Known As - KDN.T01-00625NAA
Category - Reali-Slim TT Turntable Thin Section Bearings, Internal Gear
Inner Diameter (d) inch - 5.422
Outer Diameter (D) inch - 7
Recess Diameter Inner Ring (d2) inch - 6.148
Recess Diameter Outer Ring (D2) inch - 6.356
Dynamic Load Rating, Radial Direction (CK) lbf - 950
Basic Load Rating, Moment Dynamic (CM) lbf·inch - 2030
Basic Load Rating, Radial Static (C0) lbf - 1900
Basic Load Rating, Axial Static (C0a) lbf - 4740
Basic Load Rating, Moment Static (C0M) lbf·inch - 5930
Static Torque (lbf·inch) - 11.3
Weight (kg) - 0.44452016
Attachment Holes, Inner Ring (J) inch - 5.813
Attachment Holes, Outer Ring (J1) inch - 6.688
Gear (J2) inch - 5.453
Number of Teeth - 349
** Images are for representation purposes only
