T01-00450NAA KAYDON


Country Of Origin: USA
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - KAYDON
Item Number - T01-00450NAA KAYDON
Also Known As - KDN.T01-00450NAA
Category - Reali-Slim TT Turntable Thin Section Bearings, Internal Gear
Inner Diameter (d) inch - 3.672
Outer Diameter (D) inch - 5.25
Recess Diameter Inner Ring (d2) inch - 4.398
Recess Diameter Outer Ring (D2) inch - 4.606
Dynamic Load Rating, Radial Direction (CK) lbf - 780
Basic Load Rating, Moment Dynamic (CM) lbf·inch - 1320
Basic Load Rating, Radial Static (C0) lbf - 1370
Basic Load Rating, Axial Static (C0a) lbf - 3410
Basic Load Rating, Moment Static (C0M) lbf·inch - 3070
Static Torque (lbf·inch) - 7.9
Weight (kg) - 0.3175144
Attachment Holes, Inner Ring (J) inch - 4.063
Attachment Holes, Outer Ring (J1) inch - 4.938
Gear (J2) inch - 3.703
Number of Teeth - 237

** Images are for representation purposes only
