Description
Brand - SILVERTHIN
Item Number - SM20013BR0 SILVERTHIN
Category - Back-to-Back Paired Angular Contact Thin Section Bearing
Separator - Brass; one piece pocket separator
Precision Class - ABEC Class 1
Bearing Type - Duplexed (Back-to-Back) (Type B)
Seals, Shields - None (Open)
Principal Dimensions & Load Ratings (Metric) :
Bore (B) - 200 mm
Outside Diameter (D) - 226 mm
Width - 13 mm
Land Diameter (L1) - 209.7 mm
Land Diameter (L3) - 219.4 mm
Approximate Weight - 1.22 kg
Static Radial Load - 59740 N
Dynamic Radial Load - 23530 N
Static Thrust Load - 106175 N
Dynamic Thrust Load - 35140 N
Static Moment Load - 4970 N-m
Dynamic Moment Load - 1960 N-m
Description of Suffixes :
B - Duplexed Back-to-Back
R - Brass, one piece circular pocket A
0 - ABEC Class 1
Other salient points to be noted :
• Brass; one piece pocket separator 1/4" balls
• Load capacities are not additive
• Note 2 : The maximum shaft or housing fillet radius that the bearing corners will clear for this series is 1.5mm (refer to the image)
• Race Width Tolerance: +0.000 to -0.254mm
Interchange :
SILVERTHIN - SM20013BRO
KAYDON - K20013BR0
♦ ♦ Images are for representation purposes only
