Description
Brand - ZEN
Item Number - SLR202-NPPU ZEN
Category - LR Series (Track Rollers)
Inner Ring Dimension (d) mm - 15
Outer Ring Dimension (D) mm - 40
Width (B) mm - 11
Radius (rs) mm - 0.6
Dynamic Load Rating (N) - 5200
Static Load Rating (N) - 2640
Limiting Speed (NPP and NPPU) - 11
Weight (kg) - 0.07
Radial Play - 0.003-0.018
Outer Ring Material - AISI420
Inner Ring Material - AISI420
Ball Material - AISI420
** Images are for representation purposes only
