Description
Brand - INA
Item Number - SL185052-TB-BR-C3-2S INA
Also known as - 535306240034
Category - Cylindrical Roller Bearing Double Row
Inner (d) MM - 240
Outer (D) MM - 400
Width (B) MM - 190
Inner (d) Inch - 9.4488
Outer (D) Inch - 15.748
Width (B) Inch - 7.4803
Weight (kg) - 82.6
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - FC - Full Complement, No Cage
External Modification - No External Modification
Radial Internal Play - C3 Internal Play (Higher than Cn)
Precision - BR + 2S
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
** Images are for representation purposes only
