Description
Brand - INA
Item Number - SL1828/950-TB-N1-BR-SP5-CN/3L INA
Inner (d) MM - 950
Outer (D) MM - 1150
Width (B) MM - 118
Inner (d) Inch - 37.4016
Outer (D) Inch - 45.2756
Width (B) Inch - 4.6457
Weight (kg) - 253
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - FC - Full Complement, No Cage
External Modification - N1 - 1 Locking Groove in Outer Ring
Radial Internal Play - Lower Half of Normal Clearance
Precision - P5 Precision (Higher than P6)
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
** Images are for representation purposes only
