Description
Brand - INA
Item Number - SL18-2236A C3 INA
Also known as - NCF2236V/C3
Inner (d) MM - 180
Outer (D) MM - 320
Width (B) MM - 86
Inner (d) Inch - 7.0866
Outer (D) Inch - 12.5984
Width (B) Inch - 3.3858
Weight (kg) - 29.8
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - FC - Full Complement, No Cage
External Modification - No External Modification
Radial Internal Play - C3 Internal Play (Higher than Cn)
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
** Images are for representation purposes only
