Description
Brand - INA
Item Number - SL045020-D-PP-2NR INA
Also known as - 0861835240000 E5020NRNT NAS5020UUNR NNF5020ADB.2LSV NNF5020ADB-2LSV
EAN - 4054364897383
Inner (d) MM - 100
Outer (D) MM - 150
Width (B) MM - 67
Inner (d) Inch - 3.937
Outer (D) Inch - 5.9055
Width (B) Inch - 2.6378
Weight (kg) - 3.95
Bore - C - Cylindrical Bore
Seal - 2L - LS-seal at Both Sides
Cage Type - FC - Full Complement, No Cage
External Modification - 2R - 2 Snap Rings in O.D.
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
** Images are for representation purposes only
