Description
Brand - INA
Item Number - SL045007-PP-C3 INA
Also known as - 0017224170030 NNF5007ADA-2LSV/C3
EAN - 4012802135145
Inner (d) MM - 35
Outer (D) MM - 62
Width (B) MM - 36
Inner (d) Inch - 1.378
Outer (D) Inch - 2.4409
Width (B) Inch - 1.4173
Weight (kg) - 0.48
Bore - C - Cylindrical Bore
Seal - 2L - LS-seal at Both Sides
Cage Type - FC - Full Complement, No Cage
External Modification - No External Modification
Radial Internal Play - C3 Internal Play (Higher than Cn)
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
** Images are for representation purposes only
