Description
Brand - INA
Item Number - SL04190-D-PP INA
Also known as - 894134740000
EAN - 4054369725391
Inner (d) MM - 190
Outer (D) MM - 260
Width (B) MM - 80
Inner (d) Inch - 7.4803
Outer (D) Inch - 10.2362
Width (B) Inch - 3.1496
Weight (kg) - 12.7
Bore - C - Cylindrical Bore
Seal - 2L - LS-seal at Both Sides
Cage Type - FC - Full Complement, No Cage
External Modification - No External Modification
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
** Images are for representation purposes only
