Description
Brand - INA
Item Number - SL04180-D-PP-C3 INA
Also known as - 896524790030
EAN - 4054369582260
Inner (d) MM - 180
Outer (D) MM - 240
Width (B) MM - 80
Weight (kg) - 9.8
Bore - C - Cylindrical Bore
Seal - 2L - LS-seal at Both Sides
Cage Type - FC - Full Complement, No Cage
External Modification - No External Modification
Radial Internal Play - C3 Internal Play (Higher than Cn)
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
** Images are for representation purposes only
