Description
Brand - ZEN
Item Number - SFB209 ZEN
Category - Stainless Steel Pillow Blocks (SFB)
Inner Diameter (d) mm - 45
J (mm) - 65
Overall Length (h) mm - 174
c (mm) - 54
f (mm) - 42.9
L (mm) - 21.8
g (mm) - 18.3
e (mm) - 38
a (mm) - 76
s (mm) - 11
b (mm) - 80
Weight (kg) - 1.91
Bearing - SUC209
** Images are for representation purposes only
