Description
Brand - ZEN
Item Number - SFB207 ZEN
Category - Stainless Steel Pillow Blocks (SFB)
Inner Diameter (d) mm - 35
J (mm) - 60.3
Overall Length (h) mm - 156
c (mm) - 50.8
f (mm) - 31.7
L (mm) - 21
g (mm) - 12.7
e (mm) - 36.5
a (mm) - 62
s (mm) - 13
b (mm) - 83
Weight (kg) - 1.16
Bearing - SUC207
** Images are for representation purposes only
