Description
Brand - ZEN
Item Number - SFB206 ZEN
Category - Stainless Steel Pillow Blocks (SFB)
Inner Diameter (d) mm - 30
J (mm) - 52.4
Overall Length (h) mm - 137
c (mm) - 47.6
f (mm) - 31.7
L (mm) - 18.6
g (mm) - 9.5
e (mm) - 32
a (mm) - 55
s (mm) - 10
b (mm) - 70
Weight (kg) - 0.77
Bearing - SUC206
** Images are for representation purposes only
