Description
Brand - ZEN
Item Number - SFB204 ZEN
Category - Stainless Steel Pillow Blocks (SFB)
Inner Diameter (d) mm - 20
J (mm) - 42.9
Overall Length (h) mm - 108
c (mm) - 38.1
f (mm) - 22
L (mm) - 15.9
g (mm) - 8
e (mm) - 25.4
a (mm) - 52
s (mm) - 10
b (mm) - 60.3
Weight (kg) - 0.39
Bearing - SUC204
** Images are for representation purposes only
