SD110XP0 RBC

RBC

Download Data Sheet

Country Of Origin: USA

Variant

Share this product

Brand - RBC
Item Number - SD110XP0*RBC
Category - 4-Point Contact, X-Type Thin Section Ball Bearings

Imperial :
-----------------------------------------
Bore Diameter (B) inch - 11
Outside Diameter (D) inch - 12
Width (W) inch - 0.5
Land Diameter of Inner Ring (Li) inch - 11.375
Land Diameter of Outer Ring (Lo) inch - 11.625
Housing Fillet (f1) inch - 0.06
Ball Diameter (inch) - 0.25
Ball Quantity - 69
Approximate Weight (lbs) - 2.06
Radial Static Load (lbf) - 7870
Radial Dynamic Load (lbf) - 3981
Thrust Static Load (lbf) - 19670
Thrust Dynamic Load (lbf) - 6830
Moment Static Load (lbf-in) - 45230
Moment Dynamic Load (lbf-in) - 17173

Metric :
-----------------------------------------
Bore Diameter (B) mm - 279.4
Outside Diameter (D) mm - 304.8
Width (W) mm - 12.7
Land Diameter of Inner Ring (Li) mm - 288.93
Land Diameter of Outer Ring (Lo) mm - 295.28
Housing Fillet (f1) mm - 1.52
Approximate Weight (kg) - 0.934
Radial Static Load (N) - 35010
Radial Dynamic Load (N) - 17710
Thrust Static Load (N) - 87500
Thrust Dynamic Load (N) - 30380
Moment Static Load (Nm) - 5110
Moment Dynamic Load (Nm) - 1940

Description of Suffixes and Prefixes :
-----------------------------------------
S - No seals or shields
D - Standard Width
X - 4-Point Ball Contact
P - Brass or (Composite)
0 - ABEC 1F

Notes about this Bearing :
-----------------------------------------
• 440C Stainless Steel
• Large Diameter
• Light Weight
• Small Cross Section
• Snap-Over Ball Separator

* The alphanumeric identification system is used under license.
** Images are for representation purposes only
