SBB 76 IKO

IKO

Download Data Sheet

Country Of Origin: JAPAN

Variant

Share this product

Brand - IKO
Item Number - SBB 76 IKO
Also Known As - SBB76
Category - Steel-on-Steel Spherical Bushings Inch Series
Shaft Diameter (mm) - 120.65
Shaft Diameter (inch) - 4.75
Bore Diameter (d) mm - 120.65
Bore Diameter (d) inch - 4.75
Outer Diameter (D) mm - 187.325
Outer Diameter (D) inch - 7.375
Width (B) mm - 105.56
Width (B) inch - 4.156
Boundary Dimension (C) mm - 90.47
Boundary Dimension (C) inch - 3.562
Boundary Dimension (dk) mm - 173
Boundary Dimension (dk) inch - 6.811
Minimum Radial Internal Clearance (mm) - 0.13
Maximum Radial Internal Clearance (mm) - 0.23
Mounting Dimension (d1) mm - 136.8
Maximum Mounting Dimension (ras) mm - 0.8
Maximum Mounting Dimension (rbs) mm - 1.1
Dynamic Load Capacity (Cb) N - 1530000
Static Load Capacity (Cs) N - 9210000
Weight (kg) - 11.6
Bearing with Seals - SBB 76-2RS

** Images are for representation purposes only
