Description
Brand - IKO
Item Number - SBB 72-2RS IKO
Also Known As - SBB72-2RS
Category - Steel-on-Steel Spherical Bushings Inch Series
Shaft Diameter (mm) - 114.3
Shaft Diameter (inch) - 4.5
Bore Diameter (d) mm - 114.3
Bore Diameter (d) inch - 4.5
Outer Diameter (D) mm - 177.8
Outer Diameter (D) inch - 7
Width (B) mm - 100
Width (B) inch - 3.937
Boundary Dimension (C) mm - 85.72
Boundary Dimension (C) inch - 3.375
Boundary Dimension (dk) mm - 164
Boundary Dimension (dk) inch - 6.457
Minimum Radial Internal Clearance (mm) - 0.13
Maximum Radial Internal Clearance (mm) - 0.23
Mounting Dimension (d1) mm - 129.8
Maximum Mounting Dimension (ras) mm - 0.8
Maximum Mounting Dimension (rbs) mm - 1.1
Dynamic Load Capacity (Cb) N - 1380000
Static Load Capacity (Cs) N - 8270000
Weight (kg) - 9.94
Bearing without Seals - SBB 72
** Images are for representation purposes only
