Description
Brand - IKO
Item Number - SBB 68-2RS IKO
Also Known As - SBB68-2RS
Category - Steel-on-Steel Spherical Bushings Inch Series
Shaft Diameter (mm) - 107.95
Shaft Diameter (inch) - 4.25
Bore Diameter (d) mm - 107.95
Bore Diameter (d) inch - 4.25
Outer Diameter (D) mm - 168.275
Outer Diameter (D) inch - 6.625
Width (B) mm - 94.46
Width (B) inch - 3.719
Boundary Dimension (C) mm - 80.95
Boundary Dimension (C) inch - 3.187
Boundary Dimension (dk) mm - 155
Boundary Dimension (dk) inch - 6.102
Minimum Radial Internal Clearance (mm) - 0.13
Maximum Radial Internal Clearance (mm) - 0.23
Mounting Dimension (d1) mm - 122.6
Maximum Mounting Dimension (ras) mm - 0.8
Maximum Mounting Dimension (rbs) mm - 1.1
Dynamic Load Capacity (Cb) N - 1230000
Static Load Capacity (Cs) N - 7380000
Weight (kg) - 8.46
Bearing without Seals - SBB 68
** Images are for representation purposes only
