Description
Brand - IKO
Item Number - SBB 60-2RS IKO
Also Known As - SBB60-2RS
Category - Steel-on-Steel Spherical Bushings Inch Series
Shaft Diameter (mm) - 95.25
Shaft Diameter (inch) - 3.75
Bore Diameter (d) mm - 95.25
Bore Diameter (d) inch - 3.75
Outer Diameter (D) mm - 149.225
Outer Diameter (D) inch - 5.875
Width (B) mm - 83.34
Width (B) inch - 3.281
Boundary Dimension (C) mm - 71.42
Boundary Dimension (C) inch - 2.812
Boundary Dimension (dk) mm - 137
Boundary Dimension (dk) inch - 5.394
Minimum Radial Internal Clearance (mm) - 0.13
Maximum Radial Internal Clearance (mm) - 0.23
Mounting Dimension (d1) mm - 108.4
Maximum Mounting Dimension (ras) mm - 0.6
Maximum Mounting Dimension (rbs) mm - 0.8
Dynamic Load Capacity (Cb) N - 960000
Static Load Capacity (Cs) N - 5760000
Weight (kg) - 5.87
Bearing without Seals - SBB 60
** Images are for representation purposes only
