SBB 40 IKO

IKO

Download Data Sheet

Country Of Origin: JAPAN

Variant

Share this product

Brand - IKO
Item Number - SBB 40 IKO
Also Known As - SBB40
Category - Steel-on-Steel Spherical Bushings Inch Series
Shaft Diameter (mm) - 63.5
Shaft Diameter (inch) - 2.5
Bore Diameter (d) mm - 63.5
Bore Diameter (d) inch - 2.5
Outer Diameter (D) mm - 100.012
Outer Diameter (D) inch - 3.9375
Width (B) mm - 55.55
Width (B) inch - 2.187
Boundary Dimension (C) mm - 47.62
Boundary Dimension (C) inch - 1.875
Boundary Dimension (dk) mm - 91
Boundary Dimension (dk) inch - 3.583
Minimum Radial Internal Clearance (mm) - 0.1
Maximum Radial Internal Clearance (mm) - 0.2
Mounting Dimension (d1) mm - 72
Maximum Mounting Dimension (ras) mm - 0.6
Maximum Mounting Dimension (rbs) mm - 0.8
Dynamic Load Capacity (Cb) N - 425000
Static Load Capacity (Cs) N - 2550000
Weight (kg) - 1.85
Bearing with Seals - SBB 40-2RS
