Description
Brand - IKO
Item Number - SBB 36-2RS IKO
Also Known As - SBB36-2RS
Category - Steel-on-Steel Spherical Bushings Inch Series
Shaft Diameter (mm) - 57.15
Shaft Diameter (inch) - 2.25
Bore Diameter (d) mm - 57.15
Bore Diameter (d) inch - 2.25
Outer Diameter (D) mm - 90.488
Outer Diameter (D) inch - 3.5625
Width (B) mm - 50.01
Width (B) inch - 1.969
Boundary Dimension (C) mm - 42.85
Boundary Dimension (C) inch - 1.687
Boundary Dimension (dk) mm - 82
Boundary Dimension (dk) inch - 3.228
Minimum Radial Internal Clearance (mm) - 0.1
Maximum Radial Internal Clearance (mm) - 0.2
Mounting Dimension (d1) mm - 64.9
Maximum Mounting Dimension (ras) mm - 0.6
Maximum Mounting Dimension (rbs) mm - 0.8
Dynamic Load Capacity (Cb) N - 345000
Static Load Capacity (Cs) N - 2070000
Weight (kg) - 1.32
Bearing without Seals - SBB 36
** Images are for representation purposes only
