SAA17CL0 RBC

Brand - RBC
Item Number - SAA17CL0*RBC
Category - Radial Contact, C-Type Thin Section Ball Bearings

Principal Dimensions & Load Ratings (Imperial) :
Bore Diameter (B) - 1.75 inch
Outside Diameter (D) - 2.125 inch
Width (W) - 0.1875 inch
Land Diameter of Inner Ring (Li) - 1.89 inch
Land Diameter of Outer Ring (Lo) - 1.985 inch
Housing Fillet (f1) - 0.015 inch
Ball Diameter - 0.09375 inch
Ball Quantity - 33 pcs.
Approximate Weight - 0.06 lbs
Radial Static Load - 460 lbf
Radial Dynamic Load - 371 lbf

Principal Dimensions & Load Ratings (Metric) :
Bore Diameter (B) - 44.45 mm
Outside Diameter (D) - 53.975 mm
Width (W) - 4.76 mm
Land Diameter of Inner Ring (Li) - 48 mm
Land Diameter of Outer Ring (Lo) - 50.42 mm
Housing Fillet (f1) - 0.38 mm
Approximate Weight - 0.027 kg
Radial Static Load - 2050 N
Radial Dynamic Load - 1650 N

Description of Suffixes and Prefixes :
S - No seals or shields
AA - Standard Width
C - Radial Ball Contact
L - GFR Nylon
0 - ABEC 1F

Other salient Points about this Bearing :
• 440C Stainless Steel
• Large Diameter
• Light Weight
• Small Cross Section
• Snap-Over Ball Separator

* The alphanumeric identification system is used under license.

♦ ♦ Images are for representation purposes only
