SA120CP0 RBC

Brand - RBC
Item Number - SA120CP0*RBC
Category - Radial Contact, C-Type Thin Section Ball Bearings

Principal Dimensions & Load Ratings (Imperial) :
Bore Diameter (B) - 12 inch
Outside Diameter (D) - 12.5 inch
Width (W) - 0.25 inch
Land Diameter of Inner Ring (Li) - 12.188 inch
Land Diameter of Outer Ring (Lo) - 12.313 inch
Housing Fillet (f1) - 0.025 inch
Ball Diameter - 0.125 inch
Ball Quantity - 147 pcs.
Approximate Weight - 0.56 lbs
Radial Static Load - 3720 lbf
Radial Dynamic Load - 1078 lbf

Principal Dimensions & Load Ratings (Metric) :
Bore Diameter (B) - 304.8 mm
Outside Diameter (D) - 317.5 mm
Width (W) - 6.35 mm
Land Diameter of Inner Ring (Li) - 309.58 mm
Land Diameter of Outer Ring (Lo) - 312.75 mm
Housing Fillet (f1) - 0.64 mm
Approximate Weight - 0.254 kg
Radial Static Load - 16550 N
Radial Dynamic Load - 4800 N

Description of Suffixes and Prefixes :
S - No seals or shields
A - Standard Width
C - Radial Ball Contact
P - Brass or (Composite)
0 - ABEC 1F

Other salient Points about this Bearing :
• 440C Stainless Steel
• Large Diameter
• Light Weight
• Small Cross Section
• Snap-Over Ball Separator

* The alphanumeric identification system is used under license.
