Description
Brand - FAG
Item Number - S2B-60MM-HD FAG
Category - Split Cylindrical Roller Bearing Housing
Shaft Diameter (d) mm - 60
Weight (kg) - 3.4926584
Bearing Float - S2B-60MM-FL
Bearing Held - S2B-60MM-HD
Basic Dynamic Radial Load Rating (Cr) lbs - 33595
Basic Static Radial Load Rating (C0r) lbs - 42879
Basic Dynamic Axial Load Rating (Ca) lbs - 473
Maximum Limiting Speed (rpm) - 3450
Outside Diameter Bearing (Do) inch - 5
Width Inner Ring (Co) inch - 2.844
Width Outer Ring (Bo) inch - 1.531
Housing Group - 208 Grp
